Checks

testo 625

The compact instrument with built-in humidity probe head for measuring air moisture and temperature. The large 2 line display shows humidity, wet bulb temperature or dewpoint as well as temperature.

When measuring at hard-to-access points, the humidity probe head can be easily removed and attached to the handle via the probe cable (accessory).

Alternatively, the readings can be transmitted wirelessly over wide distances from the probe to the measuring instrument. To do this,

testo 625

testo 625, humidity/temperature measuring instrument, incl. plug-in humidity probe head, battery and calibration protocol

Part no. 0563 6251

the humidity probe head is attached to the radio handle (accessory) and the radio module (accessory) is added to testo 625.

• Displays temperature and relative humidity / wet bulb temperature / dewpoint

• Max./min. values

• Hold button to freeze readings

• Display light

• Auto Off function

• Patented humidity sensor

• 2 year guaranteed long-term stability

• TopSafe, instrument protection against dirt and knocks

Probe head on handle with probe wire (optional) for measurements at hard-to-access points

Probe head on radio handle (optional) for wireless data transmission over large distances

Monitoring ambient indoor air with attached humidity probe head


Accessories Ordering data	Part no.	1 Technical data
Handle for plug-in humidity probe head for connection to testo 625, probe cable included (length 120 mm)	0430 9725	Probe type	NTC	Testo humid. sensor, cap.	Type K (NiCr-Ni)
Case for measuring instrument and probes	0516 0210	Meas. range	-10 to +60 °C	0 to+100 %RH	-200 to+1370 °C
Case for measuring instrument and probes	0516 0210	Accuracy	±0.5 °C	±2.5 %RH (+5 to
TopSafe, protects from impact and dirt	0516 0221	±1 digit		+95 %RH)
TopSafe, protects from impact and dirt	0516 0221	Resolution	0.1 °C	0.1 %RH	0.1 °C
9V rech. battery for instrument, instead of battery	0515 0025	Oper. temp.	-20 to +50 °C
		Storage temp.	-40 to +85 °C
Recharger for 9V rechargeable battery, for external recharging of 0515 0025 battery		Storage temp.	-40 to +85 °C
	0554 0025	Battery type	9V block battery, 6F22
ISO calibration certificate humidity, Calibration points 11.3 %RH and 75.3 %RH at +25°C		Battery life	70 h (without radio operation)
	0520 0006	Dimensions	182 x 64 x 40 mm
DKD calibration certificate/humidity, electronic hygrometers; calibration points 11.3%RH and 75.3%RH at +25°C	0520 0206

Radio module for upgrading measuring instrument with radio option

Country versions

Radio freq.

Part no.

Radio module for measuring instrument, 869.85 MHz, approval for the countries: DE, FR, UK, BE, NL, ES, IT, SE, AT, DK, FI, HU, CZ, PL, GR, CH, PT, SI, MT, CY, SK, LU, EE, LT, IE, LV, NO

869.85 MHz FSK 0554 0188

Radio module for measuring instrument, 915.00 MHz FSK, approval for USA, CA, CL

915.00 MHz FSK 0554 0190

Radio handles, separate

Radio handles for humidity probe head

Radio handle for attachable humidity probe head (humidity probe head included in delivery of testo 625)

—

Country versions

Radio freq.

Part no.

Radio handle for plug-in probe heads, incl. T/C adapter, approval for the countries: DE, FR, UK, BE, NL, ES, IT, SE, AT DK, FI, HU, CZ, PL, GR, CH, PT, SI, MT, CY, SK, LU, EE, LT, IE, LV, NO

869.85 MHz FSK

0554 0189

Radio handle for plug-in probe heads, incl. T/C adapter, approval for USA, CA, CL

915.00 MHz FSK

0554 0191

Radio probes: General technical data

Radio immersion/penetration probe, NTC

Radio handl

Measuring rate

0.5 s or 10 adjustable

on handle

Radio

transmissio

Unidirectional

Battery type

2 x 3V button cell (CR 2032)

2 AAA

\ micro

batteries

Battery life

150 h (meas. rate 0.5 s) 2 months (meas. rate 10 s)

215 h (meas. rate 0.5 s) 6 months (meas. rate 10 s)

Oper. temp

-20 to +50 °C

Radio coverage

Up to 20 m (without

obstructions)

Storage temp. -40 to +70 °C

Protection class IP54
