Humidity probes

Meas. range Accuracy

Part no.

_ 0 to+100 ±2,5 %RH(+5 to+95 0636 9735

'" %rh %rh)

~0 12 mm -20 to+70 °C ±0.3 °C

Humidity/temperature probe

Robust humidity probe for meas. up to +125 °C, short-term up to +140 °C, 0 12 mm, e.g. exhaust ducts, and for meas. of material equilibrium moisture, e.g. bulk goods

±2 %RH(+2 to+98 %RH) 0636 2161 ±0.2 "C

0 to +100

012 mm -20 to+125 °C

300 mm

0 12 mm

±2 %RH (+2 to +98 %RH) 0636 2135 ±0.2 "C

0 to +100

%RH

0 to +40 °C

Thin humidity probe with built-in electronics, incl. 4 attachable Teflon protection caps for material moisture equilibrium measurement

04 mm

Pressure dewpoint probes

Meas. range Accuracy t90 Part no.

-30 ... +50 °C tpd ±0.9 °C tpd (+0.1 to +50 °C tpd 300 s 0636 9835

₀ _to +₁₀₀ %_RH ±1 °C tPd (-4.9 to 0 °C tpd ⁰ ^to + l⁰⁰ %^RH ±2 „c tpd (-9.9 to-5 °C tpd

±3 °C tpd(-19.9 to-10 °C tpd) ±4 °C tpd (-30 to -20 °C tpd)

300 mm

Pressure dewpoint probe for measurements in compressed air systems

-60 to +50 °C tpd ±0.8 "C tpd (-4.9 to +50 "C tpd 300 s 0636 9836

₀ _to +₁₀₀ %_RH ±1 "C (-9.9 to -5 "C tpd ⁰ + %^RH ±2 "c tpd (-19.9 to-10 "C tpd)

±3 "C tpd (-29.9 to -20 "C tpd)

±4 "C tpd (-40 to -30 "C tpd)

300 mm

Precision pressure dewpoint probe for measurements in compressed air systems, including certificate with test point -40°C tpd

Absolute pressure probes

Meas. range Accuracy

Part no.

0 to +2000 ±5 hPa hPa

0638 1835

Absolute pressure probe 2000 hPa

Air probes

Meas. range Accuracy t99 Part no.

-60 to +400 "C Class 2

25 s

0602 1793

115 mm

Robust air probe, T/C Type K

04 mm

Surface probes

Meas. range Accuracy t99 Part no.

Fast-action surface probe with sprung thermocouple strip, also for uneven surfaces, measurement range short-term to +500°C, TC Type K

-60 to +300 "C Class 2

3 s

0602 0393

115 mm

0 5 mm

012 mm

-20 to +70 "C Class 1 0614 1635

U-value: ±0.1 ±2% of fsv*

Temperature probe to determine U-value, triple sensor system for measuring wall temperature, modelling clay included

*when used with an NTC or wireless humidity probe for measuring outside temperature and 20 K difference between the air inside and outside

Radio module for upgrading measuring instrument with radio option

Country versions

Radio freq.

Part no.

Radio module for measuring instrument, 869.85 MHz, approval for the countries: DE, FR, UK, BE, NL, ES, IT, SE, AT, DK, FI, HU, CZ, PL, GR, CH, PT, SI, MT, CY, SK, LU, EE, LT, IE, LV, NO

869.85 MHz FSK

0554 0188

Radio module for measuring instrument, 915.00 MHz FSK, approval for USA, CA, CL

915.00 MHz FSK

0554 0190

Radio probes for immersion/penetration measurements

Radio immersion/penetration probes

Meas. range Accuracy

Resolution

^t99

Radio handle for attachable probe heads with T/C probe head for surface measurement

i- 105 mm -]

i^mml

^fl "' 0 5 mm "mm,⁴

-50 to +275 °C

±0.5 °C (-20 to +80 °C) ±0.8 °C (-50 to -20.1 °C) ±0.8 °C (+80.1 to +200 °C) ±1.5 °C (remaining range)

0.1 °C

water) 12 s

Country versions

Radio freq.

Part no.

Radio immersion/penetration probe, NTC, approval for the countries: DE, FR, UK, BE, PL, GR, CH, PT, SI, MT, CY, SK, LU, EE, LT, IE, LV NO

NL, ES, IT, SE, AT, DK, FI, HU, CZ,

869.85 MHz FSK

0613 1001

Radio immersion/penetration probe, NTC, approval for USA, CA, CL

915.00 MHz FSK

0613 1002

Assembled for you: Radio handles with probe head

Radio handles with probe head for air-/ immersion-penetration-meas.

Meas. range

Accuracy

Resolution

Radio handle for attachable probe heads

with T/C probe head for air and ,, ■

immersion/penetration measurement

1- 100 mm -1

r 30 H

™ 0 5 mm ⁰_m³_m⁴

-50 to +350 °C Radio handle:

Short-term to +500 °C ±(0.5 °C +0.3% of mv) (-40 to +500 °C) ±(0.7 °C +0.5% of mv) (remaining range T/C probe head: Class 2

0.1 °C(-50 to +199.9 °C) 1.0 °C (remaining range)

^t99 ⁽ⁱⁿ

water)

10 s

Country versions

Radio freq.

Part no.

Radio handle for plug-in probe heads, incl. T/C adapter, approval for the countries: DE, FR, UK, BE, DK, FI, HU, CZ, PL, GR, CH, PT, SI, MT, CY, SK, LU, EE, LT, IE, LV, NO

T/C probe head for air/immersion/penetration measurement, attachable to radio handle, T/C Type K

NL, ES, IT, SE, AT,

869.85 MHz FSK

0554 0189

0602 0293

Radio handle for plug-in probe heads, incl. T/C adapter, approval for USA, CA, CL

T/C probe head for air/immersion/penetration measurement, attachable to radio handle, T/C

Type K

915.00 MHz FSK

0554 0191 0602 0293
