48

esto 650

The right probe for every application

Temperature measurement

• DKD laboratory for temperature accredited by the PTB guarantees secure measurement values

• First DKD laboratory for surface temperature accredited by the PTB, developed together with the PTB and the University of Ilmenau

• Cross-band probe for fast surface measurements

• Customized temperature probes for your application

• System accuracy up to 0.05 °C with precision probe 0614 0240

Current-voltage measurement

• Additional connection of external measurement transmitters such as particle counters and industrial pressure transmitters, and scaling in the instrument

Probes at a glance

Fast reaction immersion/penetration probe for measuring liquids and foodstuffs

Highly accurate immersion/penetration probe with a system accuracy of 0.05 °C in the measuring range from 0 to 100 °C and a resolution of up to 0.001 °C

Fast reaction surface probe for measuring surface temperature Precision air probe for measuring the air temperature

CO and CO₂ measurement

• Long-term stable 2 beam method for measuring the reference and the measurement channel for CO₂

Magnetic probe, adhesive power approx. 10 N for measurements on metal surfaces

■r_tí i

Globe thermometer to measure radiant heat

rpm measurement

• Mechanical rpm measurement from 20 to 20,000 rpm

Current/voltage cable (± V, ± 10 V 20 mA) for example for checking stationary measurement transmitters

CO2 probe for determining indoor air quality and monitoring the workplace

<=^=_

Mechanical rpm probes for measuring rpm with various probe tips

Humidity measurement

• The first DKD laboratory for air humidity and dewpoint temperature accredited by the PTB guarantees secure measurement values

• Worldwide patented (capacitive) Testo humidity sensor

• Inter-labortory tests in national and international institutes confirms a sensor accuracy of ±1 %RH

• 2 years guaranteed long-term stability of the Testo humidity sensor under normal conditions

• Easy calibration or adjustment of the humidity probe (on site) with defined saline solutions (11.3 %RH, 33 %RH and 75.3 %RH)

Pressure measurement

• Very high accuracy in the lower measuring range (100 Pa) of ± (0.3 Pa + 0.5 % of reading)

• Temperature-compensated pressure measurement

Highly accurate reference humidity/temperature probe for highest accuracy requirements 1 %RH

Pressure dewpoint probe for measuring the pressure dewpoint up to -60 °Ctpd in compressed air systems

Robust humidity probe for equilibrium moisture or duct measurements up to 180 °C

Flexible humldty probe with mini-module for measurements e.g. at material test benches

Sword probe for measuring humidity and temperature in stacked material

aw-value set: pressure-tight precision humidity probe for determining aw-value

1

Differential (100 hPa / 10 hPa / 100 hPa / 1000 hPa / 2000 hPa) and absolute pressure probes for pressure measurement

Ü

Refrigerant proof high-pressure probes for maintenance of refrigeration systems / water measurement

'E

Wide selection of probes from page 53
