testo 175, current/voltage data logger

testo 175-S1 testo 175-S2

Easy and highly affordablelogging of current and voltage in industrial processes. testo 175- S1 can be connected, for example, to the supply line of atransmitter to log and monitorcurrent signals. The testo 175-S2 current/voltage data logger shows the scaled signal from the transmitter direct- ly on the display. Scaling is via ComSoft. The display supplies afast overview on site of the cur-rent reading, the last value sa- ved, Min/Max values and the number of values exceeded.•1-channel: External current/voltage (mA/V)•User-friendly operation, convenient analysis•Non-volatile memory for secure data, even if the battery is empty•On-site: Use testo 580 to collect data and transfer to your PC foranalysis

On-site: fastdocumentation on theinfrared printer, 6lines/second testo 175-S2 withdisplay:Direct display ofthe scaled signal Recording the current of a measurement transmitter with testo 175-S1 (without display)

testo 175-S1 testo 175-S2 Recommended Set:testo 175-S1, Starter set with fast-actionprinter

External V/mAExternal V/mA testo 175-S1, current/voltage datalogger, 1 channel, with external terminal block, wall holder and calibration protocol
testo 175-S1, current/voltage data logger, 1 channel, withexternal terminal block, wall holder and calibration protocol Part no.0563 1759 testo 175-S2, current/voltagedatalogger with display, 1 channel, with external terminal block, wallholder and calibration protocol
0563 1759 Part no.0563 1761
Lock for wall holder for testo 175/177 data loggers0554 1755 Fast testo 575 printer, incl. 1 roll of thermal paper and batteries0554 1775 ComSoft 3 Set - Basic with USB interface0554 1766

Recommended Set:testo 175-S2, starter set with limit signaloutput

testo 175-S2, current/voltage datalogger with display, 1 channel,with external terminal block, wall holder and calibration protocol 0563 1761 testo 581 alarm signal output, floating, for testo 175/1770554 1769 Technical data Ext. chann. (fixed)1
Lock for wall holder for testo 175/177 data loggers0554 1755 Meas. range0 to+1 V0 to+10 V0 to+20 mA+4 to+20 mA±0.002 V(0 to+1 V)±0.02 V(+1 to+10 V)±0.05 mA(0 to+20 mA)±0.05 mA(+4 to+20 mA)0.001 V(0 to+1 V)0.01 V(+1 to+10 V)0.01 mA(0 to+20 mA)0.01 mA(+4 to+20 mA)Accuracy±1 digit
ComSoft 3 Set - Basic with USB interface0554 1766 ResolutionMemory16000Oper. temp.-10 to+50 °CStorage temp.-40 to+70 °CBattery typeLithium batteryWeight80 gDimensions82 x 52 x 30 mm Battery life: 2.5 years with measuring cycle of 15 min (-10 to +50 °C)Measuring cycle: 1 s to 24 hSoftware: Microsoft Windows 95b / 98 / ME / NT4-Sp4 / 2000 / XP
Current/voltage Ordering data accessories see p. 45
