| | | 29 | | |
| | | |
| | | testo 880-1 | | testo 880-2 The professional thermal imager with extensive analysis functions, extendable by telephoto lens | | testo 880-3 The expert's thermal imager for the complete analysis and real image documentation of buildings, electrical systems and machines. | | |
| | | |
| | | The starter instrument for fast fault-finding and quality assurance | | |
| | | |
| | | |
| | | |
| | | High-quality wide angle lens 32° Additional functions to testo | | Additional functions to testo 880-2: • Dynamic motor focus • Real-time display of surface moisture distribution with wireless humidity probe (optional) | | |
| | | |
| | | with F1 optics • Image refresh rate 9 Hz • Detector 160 x 120 interpolated to 320 x 240 pixels • NETD < 0.1°C • Manual focus • Minimum focus distance 10 cm • Data storage device SD, 1 GB for approx. 800-1000 images testo 880-1 Part no. 0563 0880 V1 | | 880-1: Exchangeable lenses Display of surface moisture distribution 33 Hz version* Lens protection glass included | | |
| | | |
| | | |
| | | «I») | | |
| | | |
| | | testo 880-3 Part no. 0563 0880 V3 | | |
| | | testo 880-2 Part no. 0563 0880 V2 | | |
| | | |
| | | |
| | | testo 880-3 Pro-Set The expert's thermal imager with unbeatable price advantage Additionally to the delivery scope of testo 880-3, the set contains: • One telephoto lens • One addition battery • One fast charger • The sunshield testo 880-3 Pro-Set Part no. 0563 0880 V4 | | |
| | | |
| | | Ordering information | | |
| | | |
| | | | | | | | | | | | | | | Order code | testo 880-1 0563 0880 V1 | testo 880-2 0563 0880 V2 | testo 880-3 0563 0880 V3 | testo 880-3 ProSet 0563 0880 V4 | | | | Additionally in case | | | | | | | | | Lens protection glass | C1 | | | • | | | | | Telephoto lens | A1 | - | # | • | # | | | | Additional battery | D1 | | % | • | | | | | Fast charger | E1 | • | | | | | | | Sunshield | F1 | • | # | • | # | | | | Humidity measurement | B1 | - | - | • | • | | | | | | | | | | | | | |
| | | |
| | | All imagers are delivered in a robust case including SD card, USB cable, software, mains unit and adapter plate for tripod mounting. 9 Standard 9 Optional - Not available | | |
| | | |
| | | Please select the version of the thermal imager best suited to you individually from the above options, for example a testo 880-1 with additional lens protection glass, spare battery and fast charger. This combination results in the order code 0563 0880 V1 C1 D1 E1 | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
