Long-term monitoring of ambient conditions — Professional and non-stop

testo 177-H1

Sensitive products require the right ambient conditions during production and storage. Efficient measurement and documentation of the readings over months/years is possible with the testo 177-H1 professional data logger.

Additional surface, immersion and air probes can be attached to the data logger e.g. for uninterrupted measurement of the dewpoint difference.

• Long-term stable humidity sensor with fast response time

• Memory for 48,000 readings

• Control and adjustment option with adjustment set

• Protection caps for dirt-ingressed or corrosive gases

testo 177-H1

Intern. %RH, °C, °C td + extern. °C

Humidity/temperature logger, 4 channels, with internal sensors and additional external temperature probe socket, wall holder and calibration protocol

Part no. 0563 1775

Collect data on site, upload to PC and analyse

Alarm message, reliable notification when limits are exceeded

Efficient measurement of ambient conditions


	Technical data
	Chann. intern	3
	Meas. range	0 to +100 %RH -20 to +70 °C -40 to +70 °C td
	Accuracy ±1 digit	±2 %RH ±0.5 °C
	Resolution	0.1 %RH 0.1 °C 0.1 °Ctd
	Chann. external (var.) 1
	Meas. range	-40 to+120 °C
	Accuracy ±1 digit	±0.2 °C (-25 to +70 °C) ±0.4 °C (remaining range)
	Resolution	0.1 °C
	Memory	48000
	Measuring rate	2sto24h Protection class IP54
	Battery life	5 years at meas. rate of 15 min (-10 to +50 °C)
	Analysis software	MS Windows 95b / 98 / ME / NT4-Sp4 / 2000 / XP
	Oper. temp.	-20 to +70 °C Storage temp. -40 to +85 °C
	Dimensions	103x64x33 mm Weight 130g

Recommended Set: Set for logging storage conditions and additional temperature measurement


	Humidity/temperature logger, 4 channels, with internal sensors and additional external temperature probe socket, wall holder and calibration protocol	0563 1775
	Lock for wall holder for testo 175/177 data loggers	0554 1755
	Accurate imm./pen. probe, 6m cable, IP 67	0610 1725
	testo 580 data collector set with RS232, readout holders included, for testo 175/177 data loggers	0554 1778
	ComSoft 3 Set - Basic with USB interface, Basic software with diagram and table function, incl. desk-top holders, PC connection cable	0554 1767

See page 39 for Accessories Ordering data

Description

Illustration

Meas. range Accuracy

t99

Part no.

±0.2 °C (-20 to +40 °C) 1 5 g ±0.4 °C (+40.1 to +70 °C)

0628 7510

Stub probe, IP 54

±0.2-c (oto+70-C) 190 s 0628 7503*

40 mm 0 6 mm 40 mm

±0.5 °C (remaining range)

Stationary probe with aluminium sleeve, IP 65

Refrigeration storeroom probe with aluminium sleeve, IP 54, with silicone insulated ribbon cable

Conn.: Fixed cable

-40 to +90 °C (Short-term to +105 °C)

3.2 °C (0 to +70 °C)

3.4 °C (-35 to 0 °C)

3.5 °C (remaining range)

190 s 0628 0042

0 6 mm

-35 to +80 °C

3.2 °C (-25 to +74.9 °C) 5 _s3.4 °C (remaining range)

0610 1725* Conn.: Fixed cable

Accurate imm./pen. probe, 6m cable, IP 67

0628 0006*

Accurate immersion/penetration probe, cable: 1.5 m long, IP 67

3.2 °C (0 to +70 °C)

20 s 0628 7507

Conn.: Fixed cable

Wall surface temperature probe, e.g. to prove damage in building material

-50 to +150 °C

Long-term meas. range +125°C, short-term +150°C (2 minutes)

±0.5% of mv(+100to 8 S +150 °C)

±0.2 °C (-25 to+74.9 °C) ±0.4 °C (remaining range)

06132211* Conn.: Fixed cable

Stainless steel NTC food probe (IP65) with

PUR cable «^

-50 to +125 °C Long-term meas. range +125 °C, short-term +150 °C

±0.2 °C (-25 to +80 °C) 60 S ±0.4 °C (remaining range)

0613 1712 Conn.: Fixed cable

Efficient, robust NTC air probe

The specified seal class of the data loggers is achieved with these probes.

* Probe tested to EN 12830 for suitability In the transport and storage sectors
