Detector for leaks in natural gas pipes

testo 316-1

The testo 316-1 gas leak detectorquickly detects even the smallest leaks. testo 316-1

Electronic gas leak detector withflexible measurement probe andbattery

•Bendable measurement probefor inaccessible pipes•Optical and audible alarm if limitvalue is exceeded•TopSafe case protects from dirtand impact (optional)

Technical data Meas. range 0 to10,000 ppm CH
4 1st alarm limitfrom 200 ppm CH
4 2nd alarm limit10.000 ppm CH
4 Battery life> 5 hDimensions190 x 57 x 42 mm Checks for leaks in domestic gas pipes TopSafe case protectsfrom dirt and impact (optional) Accessories Ordering data Part no. Part no.0632 0316
TopSafe for testo 316, protection case incl. stand, protectsfrom dirt and impact 0516 0189
Case for instrument and probes, For safe and orderly storage 0516 0182
Transport case (plastic), for transport and secure storage of measuring instrument and accessories 0516 3120
Accessories set (for instrument without TopSafe) includes multi- function clip, carrier loop, probe holder 0554 0550

Gas detector – Detects even the smallest gas leaks

testo gas detector

According to DVGW leaflet G465-4, gas detectors are approved for above-ground gas detection up to the "lower explosive limit (LEL)". Testo's gasdetector is a multi-range gasdetector for the gas types methane, propane and hydrogen. Gas concentrations are measured by the semi-conductor sensor in the ppm range and are shown in the display with aresolution of 1 ppm. •Audible signals whenapproaching the lower explosion limit•Continuous sound and displaywhen the explosion limit is reached

Technical data Display rangeMethane CH

Propane C

H

Hydrogen H

2 Gas detection and leak location in gas pipelines andinstallations Flexible probe extensionfor difficult-to-access points

Resolution1 ppm / 0.1 Vol.%1 to 999 ppm, 0.1 to 4.4 Vol.%1 to 999 ppm, 0.1 to 1.9 Vol.% 1 to 999 ppm, 0.1 to 4.0 Vol.%First reaction>10 ppmReaction timet90Storage temp.Built-in rechargeable block, NiMH, 1600 mAh2-3 sRech. battery life>8 hWarranty2 years on instr., 1 year on sensor-25 to+70 °CDimensions190 x 40 x 28 mmEx-ProtectionSensor intrinsically safe to DMT test instituteWeight320 gOper. temp.-15 to+40 °CPower supply

testo gas detector

Gas detector incl. flexible probeextension, rechargeable battery andmains unit for mains operation andbattery recharging Part no.0632 0323
