| | | 13 | | |
| | | |
| | | | | |
| | | |
| | | The testo easyheat and easyheat.mobile software package | | |
| | | |
| | | System requirements: easyheat PC software: Microsoft Windows 98 operating system, ME 2000, from Service Package 3 up, or XP | | |
| | | The latest top technology in flue gas analysis: the testo 330 LL product line with extended sensor life not only communicates with PC but with also with your Pocket PC. Various software packages give the customer the option of adapting his testo 330 LL exactly to his communications needs. Using easyheat PC software, customer data, sites and measurements which have already been taken, are easily managed on your PC at home. easyheat.mobile Pocket PC software supports wireless communication with Windows Mobile instruments. In this way, wireless acceptance of measurement data to the mobile instrument is possible. Data from the Pocket PC or directly from the analyser is printed on your IrDA printer. | | |
| | | |
| | | easyheat.mobile Pocket PC software: Pocket PC with IrDA interface and touchscreen, operating system from Windows Mobile 2003 | | |
| | | |
| | | Fast-action IrDA printer: Please refer to the list of Pocket PCs tested and recommended by Testo at www. testo. d e/d o wn I oad s/easy h e at.mobile | | |
| | | |
| | | |
| | | The new testo 330-1 LL communication set •testo 330-1 LL flue gas analyser with rech. battery and calibration protocol • Power pack 100-240 V for mains operation or battery recharging in analyser • Modular flue gas probe, 300 mm immersion depth, o 8 mm •Combustion air temperature probe, 190 mm long • Fast-action IrDA printer and rechargeable battery •Full version: easyheat and easyheat.mobile | | |
| | | |
| | | • USB cable connecting analyser to PC | | |
| | | |
| | | • Basic system case for analyser, probes and accessories | | |
| | | |
| | | | | | | | | | Software | Part no. | | | | Demo version easyheat and easyheat.mobile. Demo version of PC and Pocket PC software, 30 day test version | 0554 1212 | | | | easyheat PC analysis software, shows measurement in form of diagrams, tables and manages customer data. Please order USB cable 0449 0047 separately. | 0554 3332 | | | | Update: easyheat.mobile. Software for Pocket PC for mobile applications. Only for customers who already have easyheat PC software in use. | 0554 1211 | | | | Full version easyheat and easyheat.mobile. Software package for PC and Pocket PC. Please order USB cable 0449 0047 separately. | 0554 1210 | | | | Accessories Ordering data | Part no. | | | | USB connection cable, instrument to PC | 0449 0047 | | | | Testo IrDA printer with bidirectional IrDA interface and rech. battery, for communication between 330 LL and Pocket PC | 0554 0548 | | | | Spare thermal paper for printer (6 rolls), permanent ink | 0554 0568 | | | | | | | | | |
| | | Part no. | | 0563 3324 75 | | |
| | | |
| | | The new testo 330-2 LL communication set | | |
| | | |
| | | •testo 330-2 LL flue gas analyser with rech. battery and calibration protocol • Power pack 100-240 V for mains operation or battery recharging in analyser • Modular flue gas probe, 300 mm immersion depth, o 8 mm •Combustion air temperature probe, 190 mm long • Hose connection set for separate gas pressure measurement • Fast-action IrDA printer and rechargeable battery •Full version: easyheat and easyheat.mobile • USB cable connecting analyser to PC • Basic system case for analyser, probes and accessories | | |
| | | |
| | | Part no. | | 0563 3325 75 | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | |
