Air speed, temperature and moisture in one instrument Measures air flow and temperature – Flexibly and easily

testo 410

testo 410-1 measures air speedand temperature. It is ideal for spot measurements at air outlets on account of its 40 mm vane.Timed mean calclation ispossible.In addition to air speed andtemperature, testo 410-2 alsomeasures air moisture. Testo'sown, patented humidity sensor guarantees measurements you can build on. In this way, air conditions can be reliably checked. •Flow velocity measuringinstrument with temperaturemeasurement•Timed mean value calculation•Hold function and max./min.values•Windchill calculation for outsideareas (perceived temperature)•Display illumination

Attachable protective cap Flow measurement at a duct outlet with 40 mm vane

Additional b benefits o of t testo 4 410 - 2: •Air humidity measurement withlong-term stable Testo humiditysensor•Incl. dewpoint calculation andwet bulb

Technical datatesto 410-1/-2testo 410-2
Probe typeVaneNTCTesto humid. sensor,cap. Meas. range 0.4 to20 m/s-10 to+50 °C0 to100 %RH

testo 410-1 testo 410-2

testo 410-1; vane anemometer withbuilt-in NTC air thermometer, inclprotective cap, batteries and calibration protocol testo 410-2; vane anemometer withintegrated humidity measurement andNTC air thermometer, incl protective cap, batteries and calibration protocol
Resolution0.1 m/s Oper. temp.-10 to+50 °C Battery type2 batteries Type AAA Battery life testo 410-1: 100 h(average, without display illumination) testo 410-2: 60 h(average, without display illumination) Part no.0560 4101 Part no.0560 4102
Dimensions133 x 46 x 25 mm(incl. protective cap)0.1 °C±0.1 %RHAccuracy±1 digit±(0.2 m/s+ 2% ofmv)±0.5 °C±2.5 %RH(5 to95%RH)

testo 405

testo 405 is a thermalanemometer. It allows the measurement of air flow velocity, volume flow and temperature. testo 405 is ideal for measuring the flow in ducts or at ductopenings or draughty windows.•Volume flow calculation up to99,990 m3/h•Ideal for measurements in ducts•Telescopic handle to 300 mm testo 405

testo 405; thermal anemometer withduct holder, holding clip, batteryincluded Part no.0560 4053 Flow velocity measurement at nontight windows Easy-to-read readingsthanks to swivel display Accessories Ordering data Part no. Technical data testovent 410, volume flow funnel, Ø190mm/330x330 mm, incl. case0554 0410 Probe typeThermal NTC testovent 415, volume flow funnel, Ø 190mm/210x210 mm, incl. case0554 0415 Accuracy±1 digit±(0.1 m/s+ 5% of mv) (0 to+2 m/s)±(0.3 m/s+ 5% of mv) (remaining range)Meas. range0 to10 m/s0 to+99990 m³/hResolution0.01 m/s ±0.5 °C-20 to+50 °C0.1 °C ISO calibration certificate velocity, two point calibration;calibration points 5m/s and 10m/s 0520 0094 ISO calibration certificate velocity, hot wire,vane anemometer, Pitot tube; calibration points1; 2; 5; 10 m/s0520 0004 Oper. temp.0 to+50 °CStorage temp.-20 to+70 °C Battery lifeApprox.20 h Dimensions490 x 37 x 36 mm
