A guide to the world’s finest water samplers and accessories Sampllerr Sourrce Book 2009 ®

Integrated Manufacturing In-house design, manufacturing and assembly assure consistent quality and superior performance. You can depend on Teledyne Isco products. Worldwide Sales and Service Friendly, knowledgeable help is available in more than forty countries. Contact us today to arrange a consultation or product demonstration. Leasing The ideal way to avoid large capital outlays for short-term projects. Whether you need one sampler or fifty, IscoLease offers competitive rates and fast delivery. Special Applications Our Special Applications (SPA) team has solutions for any unique need –...

Open the catalog to page 2

Featured Product 1 Isco’s 4700 Refrigerated Sampler Introducing the newest addition to our sampler family. See page 14 for all the exciting details!

Open the catalog to page 3

2 Sampler Model Portable Refrigerated Portable Refrigerated GLS 3700 3710 3700C 3710C 6712 6712C 4700 6712FR Avalanche® Glacier® Collection Systems . . . . . . . . . • Stormwater . . . . • TMDL . . . . • Watershed . . . . • Resource Water . . . . • River Monitoring . . . . • YSI 600R/SDI-12 . . . . • Flow-through chamber . . . . . . . . . . . • 674 Rain Gauge . . . . • Suspension Harness . . . . . . . • ProHanger™ . . . . . . . • Street Level Installation Tool . . . . • Flowlink® Software . . . . • 581 RTD . . . . • 2105 Interface Module . . . . • Land Line Modem . . . . • 2102 Wireless...

Open the catalog to page 4

Table of Contents 5 Table of Contents Page Sampler Selection Guide . . . . . . . . . . . . . . . . . .2 Table of Contents . . . . . . . . . . . . . . . . . . . . . . . .3 Portable Samplers Ÿ GLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Ÿ 3700 Series . . . . . . . . . . . . . . . . . . . . . . . . 5-7 - 3700 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 3710 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 3700C . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 3710C . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Ÿ 6712...

Open the catalog to page 5

GLS Weight: (dry) 24.5 lbs. 11.1 kg Dimensions: (H x D) 26.5 x 16.5 in 67.3 x 41.9 cm Operating Temperature: 32° to 120°F 0° to 49°C Controller Rating: NEMA 4X, 6 IP67 For complete information and specifications, request Data Sheet #L-1116. 4 Exclusive Quick-touch Operation for Simple Field Use Just select a sampling routine and store it as the default. Then, when in the field, call up the program with quick double-touch and hit the green “GO” button. It’s that easy! The GLS begins its pre-set routine with just the push of a button. Simplified operation means no special training is...

Open the catalog to page 6

3700 Series 5 Environmentally-sealed Controller All 3700 controller components are protected by a tough NEMA 4X, 6 (IP 67) enclosure, for submersible, water- and dust-tight, corrosion-resistant operation. Dependable Distributor A Geneva-drive distributor locks the distributor arm into exact position above the bottles, assuring accurate delivery. Superior Sample Preservation The 3700 portable sampler series features thick foam insulation (R-11) and a large ice capacity to keep your samples chilled longer. 3700 — Sequential/Composite Our 3700 Samplers collect sequential or composite samples...

Open the catalog to page 7

3700 Series 3700 Full Size – Sequential/Composite Sampler Our full-featured 3700 Sampler collects sequential or composite samples based on time or flow rate. The full-size 3700 sampler is ideal for general purpose sampling and offers features for most applications. This sampler is also offered with a jumbo base to allow for larger single bottle sampling volumes. 3700C Compact – Sequential/Composite Sampler The 3700C is ideal for moving from one site to another. Its small size and weight allows for easy installation into 18-inch/0.46 meter diameter manholes without disassembly or awkward...

Open the catalog to page 8

3700 Series 3710 Full size – Composite-only Sampler Isco’s economical 3710 Sampler provides composite sampling only, delivering savings where sequential sampling isn’t needed. 3710C Compact – Composite-only Sampler The 3710C is ideal for use in small, cramped spaces where a full-size sampler won’t fit. This sampler will pass through small or offset manholes without disassembly or awkward maneuvering. Weight: (dry) 32 lbs. 16.8 kg Dimensions: (H x D) 28.75 x 19.25 in 73.3 x 48.9 cm Operating Temperature: 32° to 120°F 0° to 49°C Controller Rating NEMA 4X, 6 IP67 For complete information and...

Open the catalog to page 9

6712 Series Ÿ Expand your monitoring capabilities with plug-in modules for flow, pH, and other parameters. Ÿ Get accurate, repeatable samples with Isco’s exclusive delivery system. Ÿ Benefit from multi-parameter capabilities and SDI-12 data logging. Superior Sample Delivery With Our High-performance Peristaltic Pump The 6712 pump delivers samples at US EPA and ISO-recommended 2.0 f/s (0.61 m/s), even at head heights of 25 ft (7.6 m). At a 3 ft. (0.9 m) head, line velocity is 3.1 f/s (0.94 m/s). Our pump revolution counter assures consistent sample volumes, even when battery power is low,...

Open the catalog to page 10

6712 Series 9 Versatile Programming Isco 6712 Standard and Enhanced program modes allow quick efficient setup for virtually any application: . Stormwater monitoring . CSO and SSO monitoring . Permit compliance . Pretreatment compliance . Surface water monitoring And with the 6712, on-line programming help is just a keystroke away. Standard Program Mode Quickly select the desired parameters and sampling sequence from the simple step-by-step menu. Choose: . When to start . Sample distribution . Volume to collect . Time- or flow-pacing For continuous sampling, just replace filled bottles with...

Open the catalog to page 11

Alarm Outputs Pace Enable Three I/O Ports Text Message Notification Program Commands 700 Series Flow Modules Cell Modem 701 Module PH/Temp ASCII Data Output Selectable 4-20 mA Outputs (3 channels) 780 Module 4-20 mA Input Isco Flow Meters 2102 Wireless Communication Link Rain Gauge Input SDI-12 Devices (up to 10) Sample Temperature Input 6712 Series 6712FR Stationary You get proven protection from exposure to hostile environments – indoors or out. The exterior is custom-molded from polyester resin fiberglass. UV-resistant gel coat provides a smooth finish for easy cleaning. An automatically...
