AWARDWINNER

DUAL VACUUM SENSOR Model 2002

® • Wide Dynamic Range: 10
-4 Torr to 1000 Torr • Piezo and Patented Thin-Film Pirani Sensor in a Single Gauge Tube • Piezo is Inherently Linear • Piezo Accuracy ±1.5% of Reading • Piezo is Gas Independent • Piezo Sensitive up to Atmosphere • Pirani Thin Film Sensor Sensitive down to 10
-4 Torr • Compact Sensor Design • Sensor Modules are Interchangeable • Over Pressure to 50 psi • Diagnostic Tube Accessory Available
MODEL 2002 WITH CONTROLLER AND DIAGNOSTIC TUBE OBE Now with Device Net

DUAL VACUUM SENSOR WITH ELECTRONICSOBE

™ • Award Winning Model 2002 Technology • Wide Dynamic Range: 1x10
-4 Torr to 1000 Torr • Combined Piezo and Pirani Sensors specifications in a Single Tube • Simple Sensor Replacement – No Calibration Required • Economical Electronics Module • Wide Input Voltage 9-30 VDC • Output Options Include: Analog (0-10v, 4-20 mA) or RS 232/485 or Device Net
™ • Configurations Available with Display and/or Process Control Relays

DIGITAL VACUUM CONTROLLER 760 Plus

• Range: 0.1 Torr to 999.9 Torr • Accuracy ±0.25% of Full Scale • Resolution: 0.1 Torr • Two Control Points • Fast Response and Linear Output • Complete Installation and Calibration Accessories • Compact Design

760s STAND-ALONE SENSOR CONFIGURATION

• Input Voltage 15-30 VDC • Optional Outputs: 0-5 VDC, 0-10 VDC, 2-10 mA, 4-20 mA • Compact • Independent of Gas Composition
THPS 760 PLUS

IONIZATION GAUGE ELECTRONICS AND SENSORS IGE-3000

• Range: 10
-10 Torr to 10
-2 Torr • Miniature Bayard-Alpert Style Package • 24 VDC Power Input • Bright LED Display • RS232/485 Communication • Two Independent TTL Setpoints • Selectable Emission Current • Dual Filaments with Status Indicators • Precision Electrometer • Stable, Accurate Electrode Voltages
Device Net is a trademark of the Open DeviceNet Association, Inc. IGE-3000
