Grooved pins - 1

T ECHNICAL INFORMATION Gr Grooved Pins ® ®

Open the catalog to page 1
Grooved pins - 2

Nom. dia. mm. 6mm 12mm 18mm 24mm 36mm 48mm 60mm 72mm kgs. ® G R O O V E D P I N S 3 058 3 x 25 Product Type diameter length (i.e. Grooved Pin S8) (d1 = 3mm) (l = 25mm) Product Identification The part number is made up of the nominal diameter and effective length. The example shown here is for Grooved Pin S8 - third length centre tapering grooves - DIN 1475. A standard part number assumes a plain steel material. Other materials should be noted at the time of specifying by quoting the appropriate material reference (see page 7). Why Use Grooved Pins ? Simple Hole Preparation Resistance To...

Open the catalog to page 2
Grooved pins - 3

G R O O V E D P I N S 4 ® Grooved Pins Standard Types Direction of Installation Grooved Pin S1 Full length tapering grooves DIN 1471 Part Number 055 Page 8 • Maximum retention over whole length produced by full length parallel grooves. • Suitable for applications involving longitudinal stress and vibration. • Replaces type 055 where improved performance is required. Grooved Pin S2 Half length tapering grooves DIN 1472 Part Number 056 Page 9 • Plain portion over half length serves as free moving hinge pin for application as a dowel pin or linkage bolt; axle or bearing pin. • Half tapered...

Open the catalog to page 3
Grooved pins - 4

G R O O V E D P I N S 7 ® Material Specifications Grooved Pins, Headed Grooved Pins & Blind Drive Pin Rivets The Tappex Grooved Pin system is manufactured in West Germany, consequently material specifications relate to DIN standards. Various options are available and these are given below together with DIN reference numbers where appropriate and the corresponding British Standard number where available. Grooved Pins DIN 1651 DIN 1651 DIN 17440 DIN 17440 DIN 17440 DIN 1747 part 1 DIN 17672 part 1 Ref W.Nr 1.0718 9SMnPb28K W.Nr 1.0727 45 S 20 K W.Nr 1.4104 X12CrMoS17 W.Nr 1.4305 X10CrNiS18 9...

Open the catalog to page 4
Grooved pins - 5

Dimensions in mm Prefered sizes in bold Typical Applications G R O O V E D P I N S 9 ® For standard tolerance information see page 6 d1 Body diameter d2 Grooved diameter l Body length r1 = d1 c Height of dome Tolerance on grooved diameter d2 up to 2mm + 0.05 2.5mm - 10mm ± 0.05 over 10mm ±0.10 Tolerance on drilled hole diameter under 1.5mm = H8 1.5mm - 3mm = H9 over 3mm = H11 Grooved Pin S2 Half length tapering grooves ...DIN 1472 Part No. 056... * The grooved diameter d2 can only be measured with a ring gauge. Grooved diameters stated in the table apply only to material 9SMnPb28K - DIN...

Open the catalog to page 5
Grooved pins - 6

G R O O V E D P I N S 11 ® * The grooved diameter d2 can only be measured with a ring gauge. Grooved diameters stated in the table apply only to material 9SMnPb28K - DIN 1651. The maximum grooved size cannot be achieved with some steels and some non-ferrous metals, particularly in the case of pins with short grooves. Dimensions in mm Prefered sizes in bold Typical Applications For standard tolerance information see page 6 d1 Body diameter d2 Grooved diameter l Body length r1 = d1 c Height of dome Tolerance on grooved diameter d2 up to 2mm + 0.05 2.5mm - 10mm ± 0.05 over 10mm ±0.10 Tolerance...

Open the catalog to page 6
Grooved pins - 7

G R O O V E D P I N S 13 ® Dimensions in mm Prefered sizes in bold Typical Applications For standard tolerance information see page 6 d1 Body diameter d2 Grooved diameter l Body length r1 = d1 r2 = m/2 Tolerance on grooved diameter d2 up to 2mm + 0.05 2.5mm - 10mm ± 0.05 over 10mm ±0.10 Tolerance on drilled hole diameter 2.0mm - 3mm = H9 over 3mm = H11 Grooved Pin S6 Half length tapering grooves annular ring Part No. 062... * The grooved diameter d2 can only be measured with a ring gauge. Grooved diameters stated in the table apply only to material 9SMnPb28K - DIN 1651. The maximum grooved...

Open the catalog to page 7
Grooved pins - 8

G R O O V E D P I N S 15 ® * The grooved diameter d2 can only be measured with a ring gauge. Grooved diameters stated in the table apply only to material 9SMnPb28K - DIN 1651. The maximum grooved size cannot be achieved with some steels and some non-ferrous metals, particularly in the case of pins with short grooves. Grooved Pin S8 Third length centre tapering grooves ...DIN 1475 Part No. 058... For standard tolerance information see page 6 d1 Body diameter d2 Grooved diameter l Body length r1 = d1 c Height of dome Dimensions in mm Prefered sizes in bold Typical Applications Tolerance on...

Open the catalog to page 8
Grooved pins - 9

G R O O V E D P I N S 17 ® G R O O V E D P I N S 16 ® Dimensions in mm Prefered sizes in bold Typical Applications For standard tolerance information see page 6 d1 Body diameter d2 Grooved diameter l Body length r1 = d1 r2 = m/2 Tolerance on grooved diameter d2 up to 2mm + 0.05 2.5mm - 10mm ± 0.05 over 10mm ±0.10 Tolerance on drilled hole diameter 2.0mm - 3mm = H9 over 3mm = H11 Grooved Pin S9 Full length tapering grooves annular ring Part No. 101... c Height of dome m Width of annular groove n Width of head g Diameter of annular groove Dimensions in mm Prefered sizes in bold Typical...

Open the catalog to page 9
Grooved pins - 10

G R O O V E D P I N S 19 ® * The grooved diameter d2 can only be measured with a ring gauge. Grooved diameters stated in the table apply only to material 9SMnPb28K - DIN 1651. The maximum grooved size cannot be achieved with some steels and some non-ferrous metals, particularly in the case of pins with short grooves. Grooved Pin S12 Third length reverse tapering grooves Part No. 060... For standard tolerance information see page 6 d1 Body diameter d2 Grooved diameter l Body length r1 = d1 c Height of dome Dimensions in mm Prefered sizes in bold Typical Applications Tolerance on grooved...

Open the catalog to page 10
Grooved pins - 11

G R O O V E D P I N S 21 ® * The grooved diameter d2 can only be measured with a ring gauge. Grooved diameters stated in the table apply only to material 9SMnPb28K - DIN 1651. The maximum grooved size cannot be achieved with some steels and some non-ferrous metals. Grooved Pin S30 Full length parallel grooves double chamfer Part No. 105... For standard tolerance information see page 6 d1 Body diameter d2 Grooved diameter l Body length r1 = d1 f Width of chamfer Dimensions in mm Prefered sizes in bold Typical Applications Tolerance on grooved diameter d2 up to 2mm + 0.05 2.5mm - 10mm ± 0.05...

Open the catalog to page 11
