Excavator TB125 - 2 / 2 Pages

R

TAKEUCHI

Օ

Leading the Way in Compact Excavators

The new model TB125 excavator is the end result of years of research, field testing,customer evaluation and product refinement. Designed and engineered from the"groundup" with the latest in compact equipment technology, they firmly establish new standardfor excavator performance, reliability, efficiency and ease of operation.

Operator Comfort

* AN ISOLATION MOUNTED PLATFORM >
* MULTI-ADJUSTABLESUSPENSION SEAT minimizes noise levels in the operators station forless operator fatigue and improved awareness ofthe machines operating functions. provides for long daysproductive operation
with minimal operatorfatigue. >
հ 12 29

Serviceability

* A RETRACTABLE SEATBELT insures easy operatoraccess, and eliminatesbothersome ajustments toproperly fit the operator.
Neatly stored seat beltsencourage operatorutilization of this criticallyimportant safety feature. >
Double Flange RollerSingle Flange Roller * THE OPERATORS PLATFORM is quickly and easilyraised for optimum machine serviceability. Maintenanceand repair time are significantly reduced through quickand unencumbered access to the starter, alternator,
battery, engine oil filter, slew motorand reduction unit, swivel joint, maincontrol valve and hoses. >
* DOUBLE-FLANGED TRACK ROLLERS provide increased roller/rail contact. Stress on
the rail is more evenly distributed for longerundercarriage life and the risk of track run-offwhen operating on slopes is virtually eliminated. >
* SHORT PITCH RUBBERTRACKS make for comfortablevibration free travel even on the
roughest job sites. >
* A GREASE GUN STORAGECOMPARTMENT is provided to helpinsure proper maintenance. >

Safety

* AN EMERGENCY ENGINE SHUT DOWN SYSTEM automatically returns the engine to low idle speed in the
event of an increase in engine coolant temperature andcompletely shuts down the engine in the event of abnormaldecrease in engine lubrication pressure. An important featurewhich helps eliminate catastrophic engine failures due toabusive or unobservant operators. >

Environmental Sensitivity

* NEW SERIES ENGINES significantly reduce noise emissionlevels for minimal disturbance in
urban areas and comply with themost stringent Worldwide exhaustemission standards. >

Ease of Operation

* BUCKET CYLINDER AND AUXILIARY CIRCUITHOSES >
* ELECTRO OVER HYDRAULIC CONTROL OF THEAUXILIARY HYDRAULIC CIRCUIT are routed through boom bracket to virtuallyeliminate hose abrasion from narrow trench wallsand debris. is located at the lefthand(LH) joystickcontrol forconvenient andcomfortable
operation ofhydraulicattachments. >
LHRH R

Options

* TKB101 HYDRAULIC BREAKERS properly matched to the machine flow, pressure,and working capacity, enables the excavator toefficiently perform concrete breaking and
demolition work. >
* EMERGENCY ALARM EQUIPPED BOOMHOLDING VALVE >
* A ONE TOUCH ENGINE DECELERATOR WITHRETURN TO PRESET ENGINE SPEED provides for maximum safety when the excavator
is used craning applications or working with menin the trench. >
* Console safely lockoutsdisable the console mountedoperating controls for safe entryand exit from the machine. is located on theright hand(RH) joystick control. It aids in reduced fuelconsumption when the excavator is temporarily idle. >
* TRAVEL ALARM is available as an optional safety precaution toaudibly alert anyone in the excavators work area
of any machine movement. >
* TRAVEL SPEED SWITCH >
* A CAST IRON WRAP AROUND COUNTERWEIGHT protects the enginecompartment born accidental damage when slewing (swinging) in confined areas. is located at the right hand(RH)travel lever for easychange to 2nd(high)speed. >
* EASY LEVER PATTERN CHANGESELECTOR VALVE >
* REAR MOUNTED WORK LIGHTS improve job site safety conditions by visuallyalerting anyone entering the excavatorsarea. provides for quick change of operation controlpatterns to accomodate operator
preference. >
* LONGER STICK ARM >
* DISC TYPE PARKING BRAKES, SPRING-APPLIED, HYDRAULICALLY RELEASED, is available for wider working range. >
* TELESCOPIC ARM for travel and slew motors supplied asstandard equipment are automatically appliedwhen motors are not in operation. is available for the longest reachto increase the working range. >
