SUCTION FILTER
:OR MINERAL BASE FLUIDS
1. SFT Suction filter is in tank filter for mineral base fluids.
2. Stainless steel wire mesh.
3. 60, 100, 150, 200 Mesh available.
PART LIST
Mesh Strainer
SUS
4
Core
SECC
3
End Plate (Lower)
SECC
2
End Plate (Upper)
SECC
1
Connecting Port
SS400
ILL.#
NAME
MATERIAL
QTY
REMARKS
■ Dimension and Standard Flow Rate
Model
Port Size
*D
B
L
fli
02
Weight(kg)
Standard Flow Rate ( Q /min)
SFT-02
Rc(PT)1/4
63
19
45
36
9
0.065
7
SFT-03
22
46
10
0.07
17
SFT-04
Rc(PT)1/2
27
71
59
12
0.095
24.5
SFT-06
Rc(PT)3/4
32
72
13
0.1
51.5
SFT-08
Rc(PT)1
82
41
85
71
14
0.19
91
SFT-10
Rc(PT)11/4
104
50
87
71
16
0.3
140
SFT-12
Rc(PT)11/2
124
55
97.5
81.5
0.39
206
SFT-16
Rc(PT)2
70
130
110
20
0.56
337
SFT-20
Rc(PT)21/2
147
85
150
128
22
0.78
605
SFT-24
Rc(PT)3
100
152
24
0.96
817
3
