Power Converters & Systems

Contents Military Products MilQor® MilCOTS Converters & Filters MilQor Hi-Rel Converters & Filters MilQor Power Systems Avionics Products AeroQor® Transportation Products RailQor® Industrial Products InQor® Power Converters NiQor® (High-Voltage) Non-Isolated DC-DC Converters AC-DC Power Supplies Telecom / Datacom Products PowerQor® and DualQor® Medical Products CFQor Mechanicals & Accessories Product Development & Manufacturing *ATCA is a registered trademark of PICMG SynQor is a leading supplier of power conversion solutions to the military, avionics, transportation, medical, industrial, telecommunications...

Power Converters & Systems Broad and Scalable Product Line Hi-Rel Products High-Reliability, Field Proven DC-DC Converters for Military/Aerospace applications • -55 °C to +125 °C full power operational temperature • Input voltage ranges from 5.5 V to 475 V • No opto-isolators • Non-hybrid, SMT construction • Conduction cooled QorSeal® packaging Military Power Systems • Designed for the extreme environmental and demanding electrical conditions of military applications • Product line includes MPC Military Power Conditioners, MPS Military Power Supplies, MINV Military Power Inverter, MAC Military...

Military Isolated DC-DC Converters Isolated Converters Mil-COTS DC-DC Converters for Military/Aerospace Applications The MilQor® series of Mil-COTS Isolated DC-DC converters brings SynQor’s field proven high-efficiency synchronous rectifier technology to the Military/Aerospace industry. These “off-the-shelf” converters are compatible with the industry standard format, operate at a fixed frequency, and follow conservative component derating guidelines. MilQor products are designed and manufactured to comply with a wide range of military standards. MCOTS Product Features • High efficiency, up to...

Military Isolated DC-DC Converters 9V 16 V MCOTS-28 Input Range: 16-40 V Transient: 16-50 V MCOTS-28E Max. Power: 510 W Input Range: 16-70 V Efficiency: Up to 95% Transient: 16-100 V Max. Power: 400 W Efficiency: Up to 95% MCOTS-28V Input Range: 9-40 V Transient: 9-55 V MCOTS-28VE Max. Power: 250 W Input Range: 9-70 V Efficiency: Up to 91% Transient: 9-100 V MCOTS-48 Max. Power: 250 W Input Range: 34-75 V Efficiency: Up to 92% Transient: 34-100 V Max. Power: 600 W Efficiency: Up to 95% MCOTS-150 Input Range: 90-210 V 90-250 V Max. Power: 150 W Efficiency: Up to 90% MCOTS-270 Input Range: 155-425...

Military Isolated DC-DC Converters MCOTS-28 Full Zeta 16-40 Vin Cont. 50 Vin 1s Trans. Absolute Max Vin = 60 V Single Output MCOTS-28 Demi 16-40 Vin Cont. 50 Vin 1s Trans. Absolute Max Vin = 60 V MCOTS-28E 16-70 Vin Cont. 100 Vin 1s Trans. Absolute Max Vin = 100 V MCOTS-28V Dual Output Demi Mega Vout 1/2 Zeta Vout 9-70 Vin Cont. 100 Vin 1s Trans. Absolute Max Vin = 100 V 90-210 Vin Cont. 250 Vin 1s Trans. Absolute Max Vin = 250 V SynQor, Inc. 155 Swanson Road, Boxborough, MA 01719-1316 USA Demi Brick 34-75 Vin Cont. 100 Vin 1s Trans. Absolute Max Vin = 100 V 16-70 Vin Cont. 100 Vin 1s Trans....

Military Isolated DC-DC Converters MCOTS-270 155-425 Vin Cont. 475 Vin 1s Trans. Absolute Max Vin = 600 V Full Tera 230-425 Vin Cont. 475 Vin 1s Trans. Absolute Max Vin = 600 V Full Peta 240-280 Vin Cont. 200-350 Vin 100ms Trans. Absolute Max Vin = 600 V MCOTS-270H 240-425 Vin Cont. 475 Vin 1s Trans. Absolute Max Vin = 600 V 200-300 Vin Cont. 350 Vin 1s Trans. Absolute Max Vin = 500 V Demi Mega 180-425 Vin Cont. 475 Vin 1s Trans. Absolute Max Vin = 600 V Full Brick Tera Product Screening SCREENING Baseplate Operating Temperature Process Description Storage Temperature Pre-Cap Inspection Temperature...

Mil-COTS DC Filter Modules SynQor provides EMI filters for the MIL-COTS DC-DC converters. All EMI filters provide high levels of differential-mode and common-mode attenuation and include stabilizing bulk capacitors and damping resistors. Filter Features • Low DC resistance • Differential-mode attenuation • Common-mode attenuation • Bulk capacitance provides input system stabilization for downstream power converters • -55 °C to +100 °C Operating Temperature • No electrolytic capacitors (all ceramic design) • High-voltage isolation between common-mode pins and input / output • Wide temperature...

Military AC Line Filters Mil-COTS AC Line Filter Modules SynQor provides AC Line filters for the Mil-COTS series of PFC modules and DC-DC converters. SynQor’s high-performance filters are designed to comply with military EMI requirements. Filter Features • Universal Input voltage range • 500 W @ 115 Vrms or 1 kW @ 230 Vrms (Eighth-Brick) • 575 W @ 115 Vrms or 1.1 kW @ 230 Vrms (Quarter-Brick) • 1 kW @ 115 V or 2 kW @ 230 V (Half-Brick) • All ceramic capacitor design • High voltage isolation between baseplate and input/output • Internally damped • -55 °C to +100 °C Operating Temperature • Low...

Military Power Factor Correction Module Power Factor Correction Mil-COTS Power Factor Correction Module The MPFCQor Power Factor Correction module is an essential building block of an AC-DC power supply. Used in conjunction with a hold-up capacitor, SynQor’s high efficiency MCOTS DC-DC converters and SynQor’s MCOTS AC line filter, the MPFCQor will draw a nearly perfect sinusoidal current (PF>0.99) from a single phase AC input. The MPFCQor module can be paralleled to achieve higher power. The module is supplied completely encased to provide protection from the harsh conditions seen in many military...

Military Isolated Power Factor Correction Module Isolated Power Factor Correction Mil-COTS Isolated Power Factor Correction Module The MPFICQor Power Factor Correction module is a high power, high efficiency AC-DC converter. It operates from a universal AC input and generates an isolated output. Both regulated and semi-regulated (droop version) modules are available. Used in conjunction with a hold-up capacitor, and SynQor’s MCOTS AC line filter, the MPFICQor will draw a nearly perfect sinusoidal current (PF>0.99) from a single phase AC input. The module is supplied completely encased to provide...
