Accessories
With two cable entries
for 1.7 – 2.3 mm cable diameter
Not suitable for voltages above 42 V ! Order number: 1-1-70-621-007
Cable gland manufacturers Pg9 (
clamping range 6 – 9 mm) Not suitable for voltages above 250 V ! Order number.: 1-1-80-652-002 42 55 Ø30.5 Ø34Pg944
Application matrix for accessories
Pressure switch rangeProtective cap1-1-70-621-007Connector plug1-1-80-652-002Connector plugwith indicator light to DIN EN 175301-803-A24 VDC: 1-1-84-652-011230 VAC: 1-1-84-652-010 0170 / 0171
••
0180 / 0181
•
(up to max. 42 V)
•
0184 / 0185
•
(for 24 V and 250 V on request)see also page 27 0190 / 0191
••
0194 / 0195
•
(for 24 V on request)see also page 29 – 30 0186 / 0187
•
(up to max. 42 V)
•
0196 / 0197
••
33
