Foot switches with radio technology
//
Series GFSI F
Features/options - Metal enclosure
- With protective shield- Available with special finish in RAL colour tones- Serial data output, output signal high on actuation- EnOcean-protocol- Data rate 120 kbps- No power supply, no wiring and pipe laying required- Multi-network capable- Easy programming of receiverStandards
//
GFSI F Technical Data
IEC 609047-5-1 Enclosure aluminium die-cast, enamel finish, RAL 5011 Cover – Pedal aluminium die-cast, enamel finish, RAL 5011 Protective shield aluminium die-cast, enamel finish, RAL 2004 Protection class IP 67 per IEC 60529 Protocol EnOcean Ambient temperature -20 ºC … +65 °C Switching frequency approx. 6000 telegrams at repetitions/h Voltage supply Electrodynamic energy generator Frequency 868.3 MHz Transmission power max. 10 mW Data rate 120 kbps Bandwidth channel 280 kHz Sensing range max. 300 m outside,max. 30 m inside
27 Actuating time min. 80 ms Note no presence signal available Ordering detailsGFSI F F radio technologyS protective shieldSeries
