Foot switches with radio technology
//
Series GFI F
Features/options - Metal enclosure- Without protective shield
- Available with special finish in RAL colour tones
- Serial data output, output signal high on actuation
- EnOcean-protocol
- Data rate 120 kbps- No power supply, no wiring and pipe laying required- Multi-network capable- Easy programming of receiverStandards IEC 609047-5-1 Enclosure aluminium die-cast, enamel finish, RAL 5011 Cover aluminium die-cast, enamel finish, RAL 2004 Pedal aluminium die-cast, enamel finish, RAL 5011
//
GFI F Technical Data
Protective shield – Protection class IP 67 per IEC 60529 Protocol EnOcean Ambient temperature -20 ºC … +65 °C Switching frequency approx. 6000 telegrams at repetitions/h Voltage supply Electrodynamic energy generator Frequency 868.3 MHz Transmission power max. 10 mW Data rate 120 kbps Bandwidth channel 280 kHz Sensing range max. 300 m outside,max. 30 m inside Actuating time min. 80 ms Note no presence signal available
26 Ordering detailsGFI F F radio technologySeries
