Pull-wire switch with radio technology
//
Series EF 41 Z
Features/options - Metal enclosure
- Integrated solar cell, no battery/rechargeable battery required
- Serial data output, output signal high on actuation- EnOcean-protocol- Data rate 120 kbps- No wiring and pipe laying required- Multi-network capable- Easy programming of receiver
//
EF 41 Z Technical Data
Standards IEC/EN 60947-5-1 Enclosure Aluminium die-cast, enamelled Cover Steel, enamelled Protection class IP 65 per IEC 60529 Protocol EnOcean Ambienttemperature –20 °C … +65 ºC Switching frequency approx. 6000 telegrams at repetitions/h Voltage supply Solar cell Frequency 868.3 MHz Transmission power max. 10 mW Data rate 120 kbps Bandwidth channel 280 kHz Sensing range max. 300 m outside,max. 30 m inside Power consumptionin sleep mode approx. 25 nA
25 Switching on with empty energy supply <10 min at 400 lx Charging time with empty energy supply approx. 6 hat 400 lx, approx. 1.5 h at1000 lx Charging time at operation limit 1 hat 400 lx, approx. 15 min at 1000 lx Operation time indarkness approx. 48 h, with presence signal every 3h,when the goldcap is totally charged at 1000 lx
Contact travel 1 NO contactEF 41 Z Ordering detailsEF 41 WZ Actuator ZWatertight collarSeries 41F radio technology
