Position switch with radio technology

//

Series EF 41

Features/options - Metal enclosure - Integrated solar cell, no battery/rechargeable battery required - Serial data output, output signal high on actuation- EnOcean-protocol- Data rate 120 kbps- No wiring and pipe laying required- Multi-network capable- Easy programming of receiver

//

EF 41 Technical Data

Standards IEC/EN 60947-5-1 Enclosure Aluminium die-cast, enamelled Cover Steel, enamelled Protection class IP 65 per IEC 60529 Protocol EnOcean Ambienttemperature –20 °C … +65 ºC Switching frequency approx. 6000 telegrams at repetitions/h Voltage supply Solar cell Frequency 868.3 MHz Transmission power max. 10 mW Data rate 120 kbps Bandwidth channel 280 kHz Sensing range max. 300 m outside,max. 30 m inside
18 Power consumptionin sleep mode approx. 25 nA Switching on with empty energy supply <10 min at 400 lx Charging time with empty energy supply approx. 6 hat 400 lx, approx. 1.5 h at1000 lx Charging time at operation limit 1 hat 400 lx, approx. 15 min at 1000 lx Operation time indarkness approx. 48 h, with presence signal every 3h,when the goldcap is totally charged at 1000 lx Actuating time min. 80 ms
Contact travel 1 NO contactEF 41 Ordering detailsEF 41 WH Actuator H (R, TK, D, etc. …)Watertight collarSeries 41F radio technology
