Position switch with radio technology //Series EF 95
Features/options
- Transversely slotted mounting holes
- To EN 50 047
- Serial data output, output signal high on actuation
- EnOcean-protocol
- Data rate 120 kbps
- No power supply, no wiring and pipe laying required
- Multi-network capable
- Easy programming of receiver
// EF 95
Technical Data
IEC/EN 60947-5-1
Glassfibre reinforced thermoplastic, self-extinguishing UL 94-V0 Glassfibre reinforced thermoplastic, self-extinguishing UL 94-V0 IP 67 per IEC 60529 EnOcean
-20 °C ... +65 °C
approx. 6000 telegrams at repetitions/h Electrodynamic energy generator 868.3 MHz max. 10 mW 120 kbps 280 kHz
max. 300 m outside, max. 30 m inside min. 80 ms
no presence signal available
Standards Enclosure
Cover
Protection class Protocol Ambient temperature switching frequency Voltage supply Frequency Transmission power Data rate
Bandwidth channel Sensing range
Actuating time Note
.st«rte
M20x1,5
Contact travel q
Ordering details EF 95 WH
1 NO contact EF 95 [
Actuator H (R, D, DS, etc. ...] Watertight collar Series F radio technology
.steute
