Door handle switch with radio technology
//
Series TGFM
Features/options - Metal enclosure- Enabling push button
- Integrated solar cell, no battery/rechargeable battery required
- Serial data output, output signal high on actuation
- EnOcean-protocol
- Data rate 120 kbps- No wiring and pipe laying required- Multi-network capable- Easy programming of receiver
//
TGFM Technical Data
Enclosure
Aluminium anodised, stainless steel or aluminium black anodised Protection class IP 67 per IEC 60529 Switching system push button Protocol EnOcean Ambienttemperature –20 °C … +65 ºC Switching frequency approx. 6000 telegrams at repetitions/h Voltage supply Solar cell Frequency 868.3 MHz Transmission power max. 10 mW Data rate 120 kbps Bandwidth channel 280 kHz Sensing range max. 300 m outside,max. 30 m inside Power consumptionin sleep mode
12 approx. 25 nA Switching on with empty energy supply <10 min at 400 lx Charging time with empty energy supply approx. 6 hat 400 lx, approx. 1.5 h at1000 lx Charging time at operation limit 1 hat 400 lx, approx. 15 min at 1000 lx Operation time indarkness approx. 48 h, with presence signal every 3h,when the goldcap is totally charged at 1000 lx Ordering detailsTGFM M modular designF radio technologyDoor handle switchOther handle lengths and several push buttons available on request.
