Door handle switch with radio technology

//

Series TGF

Features/options - Thermoplastic enclosure- Enabling push button - Integrated industrial solar cell, no battery/rechargeable battery required - Serial data output, output signal high on actuation - EnOcean-protocol - Data rate 120 kbps- No wiring and pipe laying required- Multi-network capable- Easy programming of receiver

//

TGF Technical Data

Enclosure glass-fibre reinforced thermoplastic POM Protection class IP 67 per IEC 60529 Switching system push button Protocol EnOcean Ambienttemperature –20 °C … +65 ºC Switching frequency approx. 6000 telegrams at repetitions/h Voltage supply Solar cell Frequency 868.3 MHz Transmission power max. 10 mW Data rate 120 kbps Bandwidth channel 280 kHz Sensing range max. 300 m outside,max. 30 m inside Power consumptionin sleep mode approx. 25 nA Switching on with empty energy supply
11 <10 min at 400 lx Charging time with empty energy supply approx. 6 hat 400 lx, approx. 1.5 h at1000 lx Charging time at operation limit 1 hat 400 lx, approx. 15 min at 1000 lx Operation time indarkness approx. 48 h, with presence signal every 3h,when the goldcap is totally charged at 1000 lx Ordering detailsTGF F radio technology Door handle switch
