Position switches

//

Series ES/EM 14

Features/Options - Thermoplastic enclosure - Double insulated X - Slow action A , change-over contact or 2 NC contacts with double break- Snap action, change-over contact with single break- Overlapping contacts available - Mounting details to DIN EN 50 047- Suitable for in-line mounting- With pre-wired cable, cable length 1 meter- Ex-Version availableStandards IEC/EN 60947-5-1 Enclosure glass-fibre reinforced, shock-proof thermo-plastic, self-extinguishing UL 94-V0

//

ES/EM 14 Technical data

Protection class IP 67 to IEC/EN 60529 Contact material silver Switching system slow or snap action; slow action positive breakNC contacts A Switching elements ES 14: change-over contact with double break,galvanically separated contact bridgesEM 14: change-over contact with single break Termination cable H05VV-F Cable section ES 14: 4 x 0.75mm
2 EM 14: 3 x 0.75 mm
2 Uimp 4 kV Ui 250 V Ithe ES 14: 6 AEM 14: 5 A
100 Ie/Ue ES 14: 6 A/250 VAC; 0.25 A/230 VDC EM 14: 5 A/250 VAC; 0.16 A/230 VDC Utilisation category AC-15, DC-13 Max. industrial fuse rating ES 14: 6 A gL/gG D-fuseEM 14: 5 A gL/gG D-fuse Ambient temperature –20 °C … +75 °C Mechanical life > 1 million operations Switching frequency 1800/h Repeat accuracy of switching points ±0.1 mm Contact opening max.2 x 4 mm Ordering detailsES 14 WR 1Ö/1S-s-1m Cable length 1 m, (2 m, 5 m, 10 m)Cable on sideContact type 1NC/1NO, (UE, 2Ö)Actuator R (H, TK, D, etc. …)Watertight collarSeriesS Slow action (M Snap action)
