Position switches
//
Series ES 13, actuators
Features/Options- Spring rod can be actuated from any direction
- Spring rod can be shortened 30 mm in actuating area
- Exact linear actuation not necessary
- Elasticity of the spring allows for deflection above the max. switching angle of 18°Features/Options- With rounded steel tip
- Spring rod can be actuated from any direction
- Elasticity of the spring allows for deflection above the max. switching angle of 18°
//
Long spring rod TL
//
Spring rod with rounded steel tip TF
98 Contact variants: switch travel/contacts Contact variants: switch travel/contacts Slow action Slow action 1 NC / 1 NO contact ES 13 TL 1Ö/1S 1 NC / 1 NO contact ES 13 TF 1Ö/1S
