Position switches
//
Series ES 13, actuators
Features/Options- Actuating speed 0.5 m/s with an actuating angle of 20°
- Can be actuated in line with or from side of switch axis
- Actuator head with captive stainless steel ball actuator
- Ball diameter 8 mm
- Exact repeatability of switching pointFeatures/Options- Actuating speed 0.5 m/s with an actuating angle of 30°
- Metal roller
- Actuator can be repositioned by 90°
//
Ball plunger for front mounting FKU
//
Roller plunger R
92 Contact variants: switch travel/contacts Contact variants: switch travel/contacts Slow action Slow action 1 NC / 1 NO contact ES 13 FKU 1Ö/1S 1 NC / 1 NO contact ES 13 R 1Ö/1S
