Position switches

//

Series ES 13

Features/Options - Thermoplastic enclosure- Double insulated X - Slow action A , change-over contact with double break- Slow action with overlapping contacts available- Max. 3 contacts- Version with 3 contacts has cable on left-hand side - Suitable for in-line mounting- With pre-wired cable, cable length 1 meter- Ex-version availableStandards IEC/EN 60947-5-1

//

ES 13

Enclosure

Technical data

glass-fibre reinforced, shock-proof thermo-plastic, self-extinguishing UL 94-V0 Protection class IP 67 to IEC/EN 60529 Contact material silver Switching system slow action, positive break NC contact A Switching elements change-over contact with double break withgalvanically separated contact bridges Termination cable H05VV-F Cable section 4 x 0.75 mm
2 Uimp 4 kV Ui 250 V Ithe 6 A Ie/Ue 6 A/250 VAC; 0,25 A/230 VDC Utilisation category AC-15, DC-13 Max. industrial fuse rating 6 A gL/gG D-fuse
88 88 88 Ambient temperature –20 °C … +75 °C Mechanical life > 1 million operations Switching frequency 1800/h Repeat accuracy of switching points ±0.1 mm Impact resistance/Contact opening max.2 x 4.5 mm Ordering detailsES 13 WR 1Ö/1S-s-B-1m Cable length 1 m, (2 m, 5 m, 10 m)Tapped bushing M16 x 1,5Cable on sideContact type 1NC/1NO, (UE, 2Ö/1S, 1Ö/2S)Actuator R (H, TK, D, etc. …)Watertight collarSeriesS Slow action
