Series ES 95 SB
Features/Options -
Thermoplastic enclosure
- Double insulated X - Slow action A , change-over contact with double break- Cable entry M20 x 1.5- Wiring compartment- Ex-version available
- With gold-plated contacts available on request- Mounting details to EN 50 047- Horizontal mounting slots- Actuator heads can be repositioned in 4 x 90°steps
- Shaft
bore ø 10 mm availableStandards IEC/EN 60947-5-1; EN 1088; BG-GS-ET-15 Enclosure glass-fibre reinforced, shock-proof thermo-plastic, self-extinguishing UL 94-V0 Actuator stainless steel 1. 4301
//
ES 95 SB
Protection class
Technical data
IP 67 to IEC/EN 60529 Contact material silver Switching system slow action, positive break NC contacts A Switching elements change-over contact with double break Zb or 2 NC contacts, galvanically separated contactbridges Termination M3 screw terminals Cable section max. 1.5 mm
2 (incl. conductor ferrules) Uimp 4 kV Ui 400 V Ithe 6 A Ie/Ue 6 A/400 VAC; 0,25 A/230 VDC
80 Utilisation category AC-15, DC-13 Max.
industrial fuse rating 6 A gL/gG D-fuse Ambient temperature –20 °C … +80 °C Mechanical life > 1 million operations Approvals Contact variants: switch travel/contacts Ordering detailsES 95 SB 1Ö/1S Slow action Contact type 1NC/1NO, (2Ö, UE)Actuator SBSeriesS Slow action 1 NC / 1 NO contact ES 95 SB 1Ö/1S 2 NCcontacts ES 95 SB 2Ö 1 NC / 1 NO contact ES 95 SB UE with overlapping
