Series ES 13 SB
Features/Options
-
Thermoplastic enclosure
- Double insulated X - Slow action A , change-over contact with double break- Slow action with overlapping contacts available- Version with cable on left-hand side available- With pre-wired cable, cable length 1 meter
- Ex-version available- With gold-plated contacts available on request- Shaft
bore ø 10 mm available- Max. 3 contacts
- Version with 3 contacts has cable on left-hand sideStandards IEC/EN 60947-5-1; EN 1088; BG-GS-ET-15 Enclosure glass-fibre reinforced, shock-proof thermo-plastic, self-extinguishing UL 94-V0 Actuator stainless steel 1. 4301
//
ES 13 SB
Protection class
Technical data
IP 67 to IEC/EN 60529 Contact material silver Switching system slow action, positive break NC contact A Switching elements change-over contact with double break Zb or 2NC contacts, galvanically separated contactbridges Termination cable H05VV-F Cable section 4 x 0.75 mm
2 Uimp 4 kV Ui 250 V Ithe 6 A Ie/Ue 6 A/250 VAC; 4 A/24 VDC
7979 Utilisation category AC-15, DC-13
79 Max.
industrial fuse rating 6 A gL/gG D-fuse Ambient temperature –20 °C … +75 °C Mechanical life > 1 million operations Contact variants: switch travel/contacts Ordering detailsES 13 SB1Ö/1S-s-1m Slow action Cable length 1 m, (2 m, 5 m, 10 m)Cable on side Contact type 1NC/1NO (2Ö/1S, 2S/1Ö)Actuator SBSeriesS Slow action 1 NC / 1 NO contact ES 13 SB 1Ö/1S 2 NC contacts ES 13 SB 2Ö
