Features/Options - Actuating speed 0.5 m/s with an actuating angle of α = 40°and α = 30°- Actuation parallel to axis of switch from below - Wear-resistant thermoplastic roller - Actuator heads can be repositioned in 4 x 90°steps - With metal roller available on request β = 30°- Wear-resistant thermoplastic roller- Actuator heads can be repositioned in 4 x 90°steps- Collar to protect against the entry of foreign bodies- With metal roller available on requestNoteActuation from the left should be avoided since this reduces the mechanical life of the position switch. Features/Options- Actuating speed 0.5 m/s with an actuating angle of

//

Long roller lever collar WHL

//

Parallel roller lever PH

67 Contact variants: switch travel/contacts Contact variants: switch travel/contacts Slow action Slow action 1 NC / 1 NO contact ES 41 WHL 1Ö/1SES 411 WHL 1Ö/1S 1 NC / 1 NO contact ES 41 PH 1Ö/1SES 411 PH 1Ö/1S 1 NC / 1 NO contact ES 41 WHL UE 1 NC / 1 NO contact ES 41 PH UE with overlapping ES 411 WHL UE with overlapping ES 411 PH UE 2 NCcontacts ES 41 WHL 2ÖES 411 WHL 2Ö 2 NCcontacts ES 41 PH 2ÖES 411 PH 2Ö
