α = 40°and Features/Options - Actuating speed 0.5 m/s with an actuating angle of 25° - Wear-resistant thermoplastic roller- Actuator can be turned 90°- Collar to protect against the entry of foreign bodies- With metal roller available on requestFeatures/Options- Actuating speed 0.5 m/s with an actuating angle of β = 25°- Wear-resistant thermoplastic roller- Actuator heads can be repositioned in 4 x 90°steps- With metal roller available on requestNoteActuation from the left should be avoided since this reduces the mechanical life of the position switch.

//

Roller plunger WR

//

Lever H

65 Contact variants: switch travel/contacts Contact variants: switch travel/contacts Slow action Slow action 1 NC / 1 NO contact ES 41 WR 1Ö/1SES 411 WR 1Ö/1S 1 NC / 1 NO contact ES 41 H 1Ö/1SES 411 H 1Ö/1S 1 NC / 1 NO contact ES 41 WR UE 1 NC / 1 NO contact ES 41 H UE with overlapping ES 411 WR UE with overlapping ES 411 H UE 2 NC contacts ES 41 WR 2ÖES 411 WR 2Ö 2 NC contacts ES 41 H 2ÖES 411 H 2Ö
