Position switches with safety function

//

Series ES 13, actuators

Features/Options- Actuating speed 0.5 m/s with an actuating angle of 20° - Can be actuated in line with or from side of switch axis - Actuator manufacturer head with captive stainless steel ball actuator - Ball diameter: 8 mm - Exact repeatability of switching pointFeatures/Options- Actuating speed 0.5 m/s with an actuating angle of 30° - Metal roller - Actuator can be repositioned by 90°

//

Ball plunger for front mounting FKU

//

Roller plunger R

28 Contact variants: switch travel/contacts Contact variants: switch travel/contacts Slow action Slow action 1 NC / 1 NO contact ES 13 FKU 1Ö/1S 1 NC / 1 NO contact ES 13 R 1Ö/1S
