// Series ST 61, actuators
Features/OptionsST 61-B1 - Rubber mounting damps vibrations on guard devices - Actuating radius on hinged guardsa = 140 mm and b = 1000 mm- x = 30 mm Features/Options ST 61-B5- Rubber mounting damps vibrations on guard devices- Especially fit for hinged guards- Actuating radius on hinged guardsa = 140 mm and b = 1000 mm- x = 15 mm NoteInserted position of actuator = 0 in switch travel diagramThe actuators are not included with the switches. // Straight actuator ST 61-B1
// Angled actuator ST 61-B5
17 // Actuating radius
- The axis of the hinge should be x mm above thetop edge of the safety switch and in the same plane - a Actuating radius to the plane of the actuator- b Actuating radius in line with the plane of theactuator- x Axial misalignment
