Position switches

//

Series ES/EM 41 and ES/EM 411, actuators

Features/Options- Mechanical locking: release by means of pushbutton - Mechanical locking V only possible for slow action - With gold-plated contacts available on requestNoteWhen used as safety switch, secure the enclosure against slipping with appropriate means, e.g. pinning. Features/Options - Actuating speed 0.5 m/s with an actuating angle of 20° - Can be actuated in line with or from side of switch axis- Actuator head with captive stainless steel ball actuator- Exact repeatability of switching point

//

ES/EM 411

//

Plunger

145

//

Mechanical locking

Contact variants: switch travel/contacts Snap actionSlow action 1 NC / 1 NO contact EM 41 1Ö/1SES 41 1Ö/1SEM 411 1Ö/1SES 411 1Ö/1S 1 NC / 1 NO contact ES 41 UE with overlapping ES 411 UE 2 NC contacts ES 41 2ÖES 411 2Ö

//

Connector M12 x 1, 5-pole
