// Series ES 95 AZ, actuators
Features/Options95 AZ-B1 -Actuating radius on hinged guardsa = 350 mm and b = 700 mm- x = 11 mm 95 AZ-B5- Especially fit for hinged guards - Actuating radius on hinged guardsa = 350 mm and b = 700 mm- x = 13.5 mm Note Inserted position of actuator = 0 in switch travel diagram The actuators are not included with the switches. // Straight actuator 95 AZ-B1
// Angled actuator 95 AZ-B5
15 // Actuating radius
- The axis of the hinge should be x mm above thetop edge of the safety switch and in the same plane - a Actuating radius to the plane of the actuator- b Actuating radius in line with the plane of theactuator- x Axial misalignment
