Series ES 95 AZ
Features/Options
-
Thermoplastic enclosure
- Double insulated X - Slow action A , change-over contact with double break- Wiring compartment- Mounting details to EN 50 047- Horizontal mounting slots
- Actuator heads can be repositioned in factory in 4 x 90°steps- With connector M12 x 1, 4-pole available- Ex-version available- Gold-plated contact possible on requestStandards IEC/EN 60947-5-1; EN 1088 Enclosure glass-fibre reinforced, shock-proof thermoplastic, self-extinguishing UL 94-V0
//
ES 95 AZ Technical data
Actuator stainless steel 1. 4301 Protection class IP 67 to IEC/EN 60529 Contact material silver Switching system slow action, positive break NC contact A Switching elements change-over contact with double break Zb or 2NC contacts, galvanically separated contactbridges Termination M3 screw terminals Cable section max. 1.5 mm
2 (incl. conductor ferrules) Uimp 4 kV Ui 250 V Ithe 6 A Ie/Ue 6 A/400 VAC
14 Utilisation category AC-15, DC-13 Max.
industrial fuse rating 6 A gL/gG D-fuse Positive break travel 9 mm Ambient temperature –20 °C … +80 °C Mechanical life > 1 million operations Approvals Contact variants: switch travel/contacts Ordering detailsES 95 AZ 1Ö/1S Slow action Contact type 1NC/1NO, (2Ö)Actuator AZSeriesS Slow action 1 NC / 1 NO contact ES 95 AZ 1Ö/1S 2 NC contacts ES 95 AZ 2Ö
