Position switches

//

Series E 12

Features/Options -Metal enclosure- Snap action, change-over contact with single break- Suitable for in-line mounting- With pre-wired cable, cable length 1 meter- Ex-Version available Standards

//

E 12 Technical data

IEC/EN 60947-5-1 Enclosure GD-AL alloy Protection class IP 67 to IEC/EN 60529 Contact material silver Switching elements change-over contact with single break Switching system snap action Termination cable H05VV-F Cable section 4 x 0.75mm
2 Uimp 4 kV Ui 250 V Ithe 5 A Utilisation category AC-15; DC-13 Ie/Ue 5 A/250 VAC; 0.16 A/230 VDC Max. industrial fuse rating 5 A gL/gG D-fuse Mechanical life > 1 million operations Switching frequency 1800/h
120 Ambient temperature –20 °C … + 75 °C Ordering detailsE 12 WKU-s-B-1m Cable length 1 m, (2 m, 5 m, 10 m)Tapped bushing M16 x 1.5Cable on sideActuator KU (H, TK, D, etc. …)Watertight collarSeries
