Position switches

//

Series ES/EM 95, actuators

Features/Options-Actuating speed 0.5 m/s with an actuating angle of = 30 °- Actuator with watertight collar- Wear-resistant thermoplastic roller- Actuator heads can be repositioned in 4 x 90°steps- Actuation parallel to axis of switch from below- Metal roller available on requestFeatures/Options-Lever angle adjustable in 10°steps - Wear-resistant thermoplastic roller - Actuator heads can be repositioned in 4 x 90°steps - Metal roller available on request

//

Parallel metal roller lever WPHM

//

Roller lever D

116 Contact variants: switch travel/contacts Contact variants: switch travel/contacts Snap actionSlow action Snap actionSlow action 1 NC / 1 NO contact EM 95 WPHM 1Ö/1SES 95 WPHM1Ö/1S 1 NC / 1 NO contact EM 95 D 1Ö/1SES 95 D1Ö/1S 1 NC / 1 NO contact ES 95 WPHM UE 1 NC / 1 NO contact ES 95 D UE with overlapping2 NC contacts
-- with overlapping2 NC contacts ES 95 WPHM 2Ö ES 95 D 2Ö 2 NO contacts ES 95 WPHM 2S 2 NO contacts ES 95 D 2S
