Series ST 14
Features/Options
-
Thermoplastic enclosure- Double insulated X - Slow action A , change-over contact with double break- Slow action with overlapping contacts available- Version with cable on left-hand side available- With pre-wired cable, cable length 1 meter
- Ex-version available- With gold-plated contacts available on request- Available with connector M12 x 1, 4-poleStandards IEC/EN 60947-5-1; EN 1088; BG-GS-ET-15
//
ST 14
Enclosure
Technical data
glass-fibre reinforced, shock-proof thermoplastic, self-extinguishing UL 94-V0 Actuator stainless steel 1. 4301 Protection class IP 67 to IEC/EN 60529 Contact material silver Switching system slow action, positive break NC contact A Switching elements change-over contact with double break Zb or 2NC contacts, galvanically separated contactbridges Termination cable 4x AWG20, UL 2464 Cable section 4 x 0.56 mm
2 Uimp 4 kV Ui 250 V Ithe 6 A
12 12 12 Ie/Ue 6 A/250 VAC; 4 A/24 VDC; 0.25 A/230 VDC Utilisation category AC-15, DC-13 Max.
industrial fuse rating 6 A gL/gG D-fuse Positive break travel 8 mm Ambient temperature –20 °C … +80 °C Mechanical life > 1 million operations Approvals Contact variants: switch travel/contacts Ordering detailsST 14 1Ö/1S-s-1m Slow action Cable length 1 m, (2 m, 5 m, 10 m)Cable on sideContact type 1NC/1NO, (2Ö, UE)SeriesSafety door switch 1 NC / 1 NO contact ST 14 1Ö/1S 1 NC / 1 NO contact ST 14 UE with overlapping2 NCcontacts ST 14 2Ö
