Features/Options - With rounded steel tip - Spring rod can be actuated from any direction- Elasticity of the spring allows for deflection above the max. switching angle of 18° Features/Options- Wear-resistant plastic rod - Spring rod can be actuated from any direction - Elasticity of the spring allows for deflection above the max. switching angle of 18°

//

Spring rod with rounded steel tip TF

//

Spring rod with plastic rod TK

109 Contact variants: switch travel/contacts Contact variants: switch travel/contacts Snap actionSlow action Snap actionSlow action 1 NC / 1 NO contact EM 14 TFES 14 TF 1 NC / 1 NO contact EM 14 TKES 14 TK
