Series RC 60
Features/Options-
Thermoplastic enclosure
- Long life
- 1 Reed contact
- Actuation from front and from side
- Switching distance up to 33 mm depending on the actuating magnet
- With pre-wired cable, cable length 1 metre
- Version with doubled switching capacity with tungsten reed contacts availableStandards IEC/EN 60947-5-1 Enclosure glass-fibre reinforced polyamide Actuator series M permanent magnet Protection class IP 67 to EN 60529 Contact material rhodium; -W: tungsten Switching system reed contacts Contact types NO contact, change-over contact or grid Termination lead-free pre-wired cable, PVC H05VV-F or 3-pole connector to DIN 41 524 Cable section 2 x 0.5 mm
//
RC 60 Technical data
2 Cable length 1, 2 oder 5 m Switching voltage max. 250 VAC/DC Switching current 1S: 2 A; 1W: 0,5 A; -W: 1 A Switching capacity 1S: max. 50 VA/ W; 1W: max. 15 VA/ W; -W: max. 25 VA/ W Switching frequency max. 200 Hz
48 Ambient temperature -10 °C … +80 ºC Mechanical life 10
9 9 operations Electrical life 10 operations Repeat accuracy ±0.02 mm 1S:20 g, 1W: 10 g Resistance to vibrations Contact variants: Switch travel/contacts Ordering dataRC 60 1W-W-ST bi-directional actuation ST plug-in connectorTungsten reed contacts1 change-over contact (1S 1 NO contact, 1Sr 1 Raster)SeriesMagnetic sensor 1 NO contact RC 60 1S 1 grid RC 60 1Sr 1 change-over contact RC 60 1W
