Series RC 30
Features/Options
-
Thermoplastic enclosure
- Long life
- 1 Reed contact
- Actuation from front and from side
- Switching distance up to 36 mm depending on the actuating magnet
- With pre-wired cable, cable length 1 metre
- Version with doubled switching capacity with tungsten reed contacts availableStandards IEC/EN 60947-5-1 Enclosure glass-fibre reinforced polyamide Actuator series M permanent magnet Protection class IP 67; with plug-in connector IP 42/65 to EN 60529
//
RC 30
Contact material
Technical data
rhodium; -W: Tungsten Switching system reed contacts Contact types NO contact or change-over contact Termination lead-free pre-wired cable, PVC H05VV-F or 3-pole connector to DIN 41 524 Cable section 2 x 0.5 mm
2 Cable length 1, 2 oder 5 m Switching voltage max. 250 VAC/DC Switching current 1S; 1W: 0,5 A; -W: 1 A Switching capacity 1S: max. 50 VA/ W; 1W: max. 15 VA/ W; -W: max. 25 VA/ W
46 Switching frequency max. 200 Hz Ambient temperature -10 °C … +80 ºC Mechanical life 10
9 9 operations Electrical life 10 operations Repeat accuracy ±0.02 mm 1S:20 g, 1W: 10 g Resistance to vibrations Contact variants: Switch travel/contacts Ordering dataRC 30 1W-W bi-directional actuation Tungsten reed contacts1 change-over contact (1S 1NO contact)SeriesMagnetic sensor 1 NO contact RC 30 1S 1 change-over contact RC 30 1W
