Series RC 20, variants
Features/Options- Coupling for magnetic sensors with plug-in connector M16 x 1:for 24 VDC Hirschmann Type Masei 3100 , protection class IP 42
for 230 VAC Binder Series 723, protection class IP 65- Version for high temperatures up to +130 °C with silicon cableavailable
//
Connector M 16x1, 3-pole
//
Angled connector M 16x1, 3-pole
43 Actuating distances Actuating direction from front from side Switch travelContacts Actuating magnetSwitching distance [mm]Switching distance [mm] 1 NO contact 1 NO contact Actuating directionN or SN or S onoffonoffM 50 U 12161114 M 100 14181215 M 100 U 16191416 M 200 19241620 M 200 U 20251721 M 300 25292124 M 300 U 25292124 M 300 U B 25302124 M 400 U 41473237 M 400 U B 41473237 M 500 20253035 M 600 39472934 M 700 40472933
