Series RC 20
Features/Options- Metal enclosure
- Long life
- 1 Reed contact
- Actuation from front and from side
- Switching distance up to 41 mm depending on the actuating magnet
- With pre-wired cable, cable length 1 metre
Standards IEC/EN 60947-5-1 Enclosure brass, nickeled Actuator series M permanent magnet Protection class IP 67; with plug-in connector IP 42/65 to EN 60529 Contact material rhodium Switching system reed contacts Contact types NO contact or change-over contact
//
RC 20
Termination
Technical data
lead-free pre-wired cable, PVC H05VV-F or 3-pole connector to DIN 41 524 Cable section 2 x 0.5 mm
2 ,3 x 0.5 mm
2 Cable length 1, 2 or 5 m Switching voltage 1S: max. 250 VAC/DC, 1W: max. 175 VAC/DC Switching current 1S: max. 0,5 A, 1W: max. 0.25 A Switching capacity 1S: max. 50 VA/W, 1W: max. 3 VA/W Switching frequency max. 200 Hz
42 Ambient temperature -10 °C … +80 ºC Mechanical life 10
9 9 operations Electrical life 10 operations Repeat accuracy ±0.02 mm 1S:20 g, 1W: 30 g Resistance to vibrations Contact variants: Switch travel/contacts Ordering dataRC 20 1W-ST bi-directional actuation with plug-in connector1 change-over contact (1S 1 NO contactSeriesMagnetic sensor 1 NO contact RC 20 1S 1 change-over contact RC 20 1W
