Series RC M20
Features/Options- Metal enclosure
- Long life
- 1 Reed contact
- Actuation from front, actuation from side only for change-over contacts- Switching distance up to 30 mm depending on the actuating magnet
- With pre-wired cable, cable length 1 metre
- Available in high-grade steelStandards IEC/EN 60947-5-1 Enclosure brass, nickeled Actuator series M permanent magnet Protection class IP 67 to EN 60529 Contact material silver Switching system reed contacts Contact types NO contact or change-over contact, grid orchange-over contact latching
//
RC M20
Termination
Technical data
Pre-wired cable, H05VV-F Cable section 1S: 3 x 0.75 mm
2 , 1W: 4 x 0.75 mm
2 Cable length 1, 2 oder 5 m Switching voltage max. 250 VAC/DC Switching current 1.5 A Switching capacity 1Ö, 1W: max. 50 VA/W, 1S: max. 100 VA/W Switching frequency max. 200 Hz Ambient temperature -10 °C … +80 ºC
40 Mechanical life 10
9 9 operations Electrical life 10 operations Repeat accuracy ±0.02 mm 1S: 50 … 100 g, 1Ö, 1W: 10 … 50 g Resistance to vibrations Contact variants: Switch travel/contacts Ordering dataRC M20 1W actuation from frontactuation from side 1 change-over contact (1Ö 1 NCcontact, 1S 1 NO contact)SeriesMagnetic sensor 1 NO contact RC M20 1S 1 grid RC M20 1SrRC M20 1Sr 1 change-over contact RC M20 1W 1 change-over contactlatching RC M20 1W r RC M20 1W r
