Series RC 15
Features/Options
- Metal enclosure
- Long life
- 1 Reed contact
- Actuation from front
- Switching distance up to 25 mm depending on the actuating magnet
- With pre-wired cable, cable length 1 metre
Standards IEC/EN 60947-5-1 Enclosure brass, nickeled Actuator series M permanent magnet Protection class IP 67 to EN 60529
//
RC 15
Contact material
Technical data
silver Switching system reed contacts Contact types NC contact, NO contact or change-overcontact Termination pre-wired cable, H05VV-F Cable section 1S: 3 x 0.75 mm
2 , 1W: 4 x 0.75 mm
2 Cable length 1, 2 or 5 m Switching voltage max. 250 VAC/DC Switching current 1.5 A Switching capacity 1Ö, 1W: max. 50 VA/W, 1S: max. 100 VA/W Switching frequency max. 200 Hz Ambient temperature -10 °C … +80 ºC
38 Mechanical life 10
9 9 operations Electrical life 10 operations Repeat accuracy ±0.02 mm 1S: 50 … 100 g, 1Ö, 1W: 10 … 50 g Resistance to vibrations Contact variants: Switch travel/contacts Ordering dataRC 15 1W frontseitige Betätigung 1 change-over contact (1Ö 1 NCcontact, 1S 1 NO contact)SeriesMagnetic sensor 1 NC contact RC 15 1Ö 1 NO contact RC 15 1S 1 change-over contact RC 15 1W
