Series RC 10
Features/Options-
Thermoplastic enclosure
- Long life
- 1 Reed contact
- Actuation from front and from side
- Switching distance up to 40 mm depending on the actuating magnet
- With pre-wired cable, cable length 1 metre
Standards IEC/EN 60947-5-1 Enclosure POM Actuator Series M permanent magnet Protection class IP 67 to EN 60529 Contact material rhodium Switching system reed contacts Contact types NO contact Termination pre-wired cable, PVC LiYY
//
RC 10
Cable section
Technical data
2 x 0.34 mm
2 Cable length 1 m Switching voltage max. 250 VAC/DC Switching current 1 A Switching capacity max. 100 W/VA Switching frequency max. 200 Hz Bounce duration – Ambient temperature -10 °C … +80 ºC
34 Mechanical life 10
9 9 operations Electrical life 10 operations Repeat accuracy ±0,02 mm 20 g Resistance to vibrations Contact variants: Switch travel/contacts Ordering dataRC 10 1S bi-directional actuation 1 NO contactSeriesMagnetic sensor 1 NO contact RC 10 1S
