Series RC Si M30
Features/Options- Metal enclosure
- Long life
- Reed contacts, coded
- Actuation from front
- Switching distance up to 8 mm
- With pre-wired cable, cable length 1 metre
Standards IEC/EN 60947-5-3; EN 954-1; EN 1088 Enclosure aluminium brass, nickeled Actuator
//
RC SI M30 Technical data
MC 30 Protection class IP 67
to IEC/EN 60529 Contact material – Switching system Reed contacts Contact types 1NC/1 NO contact or 2 NC contacts Termination Pre-wired cable H05 VV-F 5G Cable section 4 x 0.5 mm Cable length 1 m Uimp – Power consumption – – Outputs
Utilisation category Ie/Ue – Switching voltage max. 30 VDC Switching current max. 125 mA, with LED: 20 mA Switching capacity max. 6 W/VA
18 Voltage drop at Imax 2.5 V, with LED: 3 V Short-circuit current max. 750 mA for 50 ms, with LED: 30 mA Max.
industrial fuse rating – Switching frequency max. 5 Hz Ambient temperature -20 °C … +70 ºC Mechanical life > 10 Mio. operations Electrical life – 8 mm sar Switching capacity
sao 24 mm Approvals
H
Contact variants: Switch travel/contacts Ordering dataRC Si M30 1Ö/1S Bi-directional actuation 1 NC/1 NO contact (2Ö)Series, Enclosure diameter M30SafetyMagnetic sensor 1 NC/1 NO contact RC Si M30 1Ö/1S 2 NC contacts RC Si M30 2Ö
