Foot switches

//

Series GFI, variants

Features/Options - With potentiometer: Analogue output- Metal enclosure - With various potentiometers available: 1 k IEC/EN 60947-5-1 , 2 k , 5 k or 10 k - Start value can be set in factory - Without protective shield - Low pedal height - Ergonomic pedal design - Protection class IP 67/IP 68 possible on request - Wiring compartment - Available with special finish in RAL colour tonesStandards Enclosure aluminium die-cast, enamel finish, RAL 5011 Cover aluminium die-cast, enamel finish, RAL 2004 Pedal aluminium die-cast, enamel finish, RAL 5011 Protective shield – Termination soldering terminals Cable entry M20 x 1.5 Contact material silver, gold-plated Protection class IP 65 to EN 60529 Switching system potentiometer

//

GFI POTI

Resistance R

Technical data

20 … 1 k ±3 %;20 … 2 k ±3 %;50 … 5 k ±3 %;100 … 10 k ±3 % Linearity ±0.5 % Utilisation category –
30 Ie/Ue micro switch: 0.1 A/250 VAC; 0.1 A/24 VDC Switching power potentiometer: max. 1.5 W at 40 °C Max. industrial fuse rating – Ambient temperature – 15 °C … + 80 ºC Mechanical life > 1 million operations Note The built-in micro switch provides for poten-tial-free switching of the potentiometer. Contact variants: Travel/contacts Ordering detailsGFI POTI 1k 1PW Potentiometer
Micro switch 1 change-overcontact (2PW) ,other configu-rations possible 1 change-over GFI POTI … 1PW
Potentiometer value 1 k (2 k , 5 k or 10 k )Potentiometer Series 2 change-over GFI POTI … 2PW
