Foot switches

//

Series GFI, variants

Features/Options IEC/EN 60947-5-1 - With latching: ON/OFF principle- Metal enclosure - 2 contacts - Without protective shield - High level of stability - Low pedal height - Ergonomic pedal design - Protection class IP 67/IP 68 possible on request - Wiring compartment - Available with special finish in RAL colour tonesStandards Enclosure aluminium die-cast, enamel finish, RAL 5011 Cover aluminium die-cast, enamel finish, RAL 2004 Pedal aluminium die-cast, enamel finish, RAL 5011 Protective shield – Termination screw terminals Wire cross-section max. 2.5 mm

//

GFI RE Technical data

2 (incl. conductor ferrules) Cable entry M20 x 1.5 Contact material silver Protection class IP 65 to EN 60529 Switching system slow action with double break, positive breakNC contact A Switch insert ES 60 GF RE Switching element 1 NC/1 NO contact with latching Utilisation category AC-15 Ie/Ue 16 A/400 VAC
28 Max. industrial fuse rating 16 A gL/gG D-fuse Ambient temperature – 25 °C … + 80 ºC Mechanical life > 1 million operations Contact variants: Travel/contacts Ordering detailsGFI 1Ö/1S RE Slow action Latching elementContacts 1NC/1NO contactSeries 1 NC/1 NO contact GFI 1Ö/1S RE
